Mounting templates

Mounting templates are essential tools for ensuring precision, repeatability, and efficiency in industrial assembly processes.

Gambini Meccanica manufactures mounting templates for rack bars designed to guarantee correct alignment during installation and to optimize the accuracy of the transmission system. They are developed according to the modules and geometries of the racks, ensuring ease of use and reduced assembly time.

The mounting templates are made of C45 steel with induction hardening (55–58 HRC), burnishing and a ground surface, available with either helical or straight toothing. Supplied for modules from 2 to 6, they ensure fast installation, reduced errors, and maximum repeatability during assembly.

Request the technical brochure about the transmission force of our rack and pinion systems.

Request the technical brochure

MOUNTING RACKS WITH
JUST-IN-TIME DELIVERY

Are you looking for a mounting rack with STANDARD DIMENSIONS with very fast delivery time? Do you need a SAMPLE PIECE with just-in-time delivery? If you buy products In our online shop we will ship them within 3 WORKING DAYS upon receipt of payment.
Order your standard piece

CUSTOMIZED
MOUNTING RACKS

One of the key elements of Gambini Meccanica
is the technical design service: a team of specialized technicians is able to collaborate
with customers in order to meet
their design needs andto offer customized products.
Customize your product

Products range index

SERIES QUALITY MATERIAL HEAT-TREATMENT HRC SURFACE TOOTH SYSTEM MODULES
260
 – C45 induction hardened teeth + burnishing 55-58 ground helical 2_3_4_5_6
265
 – C45 induction hardened teeth + burnishing 55-58 ground straight 2_3_4_5_6
